DNH SAFE-10P-54T-MED

DNH SAFE-10P-54T-MED

The DNH SAFE-10P-54T MED is a 10 watt, 100 volt line, plastic IP55 rated cabinet speaker with a separate internal compartment for electronic components.

EN54-24 certified for voice alarm applications. Fitted with a ceramic terminal block & thermal fuse.

Compliant with the Marine Equipment Directive 2014/90/EU standard for for Safety of Life at Sea (SOLAS) Maritime applications.

The SAFE-10P54TMED is often used in indoor applications and bathrooms on ships.

Water resistant, rated IP55.

Warranty: 2 Years.



100V IPxx IP55 MED
List Ex VAT: £133.00
Log in for Trade Prices
CONTACT US

SPECIFICATIONS

Rated Power (rms) 10W
Power Taps @ 100V 10W, 5W, 2.5W, 1W
SPL (1W/1m) 72dB
Max SPL (rated/1m) 81dB
Frequency Range (-10dB) 100HZ - 17KHZ
Dispersion 1K Hz / 4K Hz 115° / 70°
Termination Ceramic terminal
Max. / min. amb. temp 90°C / -40°C
IP Rating IP55
Material / Colour ABS / White RAL9010
Weight (kg) 0.8kg
Dimensions (H x W x D) mm 104 x 206 x 53
Mounting 4 screws

DOWNLOADS

DNH SAFE10P-54T MED Datasheet
DNH SAFE-10P-54T MED Compliance Certificate
