RCF DX 4008
Click to expand

RCF DX 4008

The RCF DX 4008 4 input, 8 output digital loudspeaker management system is designed for the touring or fixed sound installation markets.

The absolute latest in available technology is utilized with 32-bit (40-bit extended) floating point processor and high performance 24-bit Analog Converters. The high-bit DSP prevents noise and distortion induced by truncation errors of the commonly used 24-bit fixed-point devices.

A complete set of parameters include I/O levels, delay, polarity, 6 bands of parametric EQ per channel, multiple crossover selections and full function limiters.

The DX 4008 can be controlled or configured in real time on the panel or with the intuitive PC GUI, XLink, accessed via the RS 232 interface. Software upgrade for CPU and DSP via PC keeps the device current with newly developed algorithms and function once available.

Multiple setup storage and system security complete this professional package.

  • Complete 4 input - 8 output digital loudspeaker management system designed for the touring or fixed sound installation markets
  • Sampling rate can be set to 96kHz
  • Precise frequency control is achieved with its 1 Hz resolution
  • Inputs and outputs can be routed in multiple configurations to meet any requirements
  • The DX 4008 is shipped with a special PC Graphic User Interface (GUI) application - XLink
  • XLink gives the user an option to control the DX 4008 unit from a remote PC via the RS232 serial communication link
  • The GUI application makes much easier control and monitor the device, allowing the user to get the whole picture on one screen
  • Programs can be recalled and stored from/to PC's hard drive, thus expanding the storage to become virtuality limitless
1U
List Ex VAT: £2,051.00
Log in for Trade Prices
CONTACT US

SPECIFICATIONS

Digital Audio Resolution

40

Sampling rate

96

A/D - D/A converters

24

Propagation delay

3

Inputs

4 x Balanced Mono XLR Line connectors

Signal outputs

8 x XLR

Processing

DSP, EQ Filters, Delay, Tone Controls

High-pass Filter

20 Hz - 20000 Hz

Crossover

20 – 20000Hz

Configuration

Front panel, PC Software

Number of programs/presets

30

Protocols for system integration

ASCII

Cooling

Convection

Fuses

Yes

Operating voltage

220-240/115 V~ 50/60Hz

Power consumption

20 W

Cabinet/Case

Material: Metal, Colour: Black

Rack mounting

19", 1U

Size H x W x D

44 mm x 483 mm x 203 mm,
1.73” x 19.02” x 7.99”

Weight

2.96 kg / 6.53 lbs
