Power source

100 - 240 V AC, 50 / 60 Hz

Power / current consumption

99 W (AC operation at 1/8 maximum output without clip)

Frequency response

50 Hz - 20 kHz

Rated output

480 W

Audio input

MIC 1: Phone jack, selectable to RJ45, Phantom Power,
MIC 2 - 3: Phone jack
MIC 4: Phone jack, selectable to AUX 1,
AUX 1: RCA pin jack, selectable to MIC 4,
AUX 2: RCA pin jack

Audio output

Speaker Out: Screw type terminal.
Direct Line (selectable): 42 Ω (100 V) or 4 Ω.

Rec Out: RCA pin jack

Control input

Priority Control Input, removable terminal block

Controls

MP3, Player/Recorder, Mic 1, Mic 2, Mic 3, Mic 4/Aux 1, Aux 2, Master, On/Off.
Bass: ±10 dB at 100 Hz.
Treble: ±10 dB at 10 kHz

Finish

ABS resin, Steel plate

Dimensions (W x H x D)

420 x 100.9 x 357 mm

Weight

5 kg

Inputs

MIC 1 : 1 mV (-60 dBV), 600 Ω, balanced, phone jack, selectable to RJ45.

MIC 2-3 : 1 mV (-60 dBV), 600 Ω, balanced, phone jack

MIC 4: 1 mV (-60 dBV), 600 Ω, balanced, phone jack, selectable to AUX 1.
AUX 1: 100 mV (-20 dBV), 10 kΩ, unbalanced, RCA pin jack, selectable to MIC 4.
AUX 2: 100 mV (-20 dBV), 10 kΩ, unbalanced, RCA pin jack.
MP3: LED Display, Support USB, SD/MMC Card (up to 32 GB), Bluetooth, Radio FM, Record.

Outputs

Speaker Out: Speaker output in screw type terminal.
Direct Line (selectable) : 42 Ω (100 V) or 4 Ω.
Rec Out: 0 dBV, 600 Ω, unbalanced, RCA pin jack
