iKON AVS SGA-40
Click to expand

iKON AVS SGA-40

The iKON AVS SGA-40 in wall stereo amplifier is designed for wall and dado mounting. It is ideal for multi-room audio, classrooms, hotel bedrooms and small meeting rooms.

The SGA40 is manufactured in the 50mm euro format and supplied complete with a UK size white mounting frame. It flush mounts into a standard UK single back box and requires only a 35mm depth. It will also fit the single DIN back box.

The highly efficient (86%) class D design and has an RMS output of 10 watts per channel when powered by the included 12V power supply. This can be increased to 17 watts per channel or 20 watts per channel into 8 Ohms when powered from a 15V or 18V power supply respectively (not included).

When no signal is present the amplifier adopts an ultra low power standby state.

There are two rear inputs on screw terminals for permanent connections and two 3.5mm stereo jacks on the front panel for other sources making the SGA-40 easy to install & use.

Designed with the European market in mind, the SGA-40 offers excellent reliability value for money.

8ohms
List Ex VAT: £98.00
Log in for Trade Prices
CONTACT US

SPECIFICATIONS

Power Output , 12V Stereo Mode 10W RMS* per channel into 8 Ohms
Power Output, 15V Stereo Mode 17W RMS* per channel into 8 Ohms
Power Output, 18V Stereo Mode 20W RMS* per channel into 8 Ohms
Bandwidth 20Hz to 22KHz +/- 1dB
THD & Noise 0.1% THD +noise & 70dB SNR
Gain 26dBu
Coupling Input: AC; Output DC.
Minimum input for full power -6dB
Protection Integral, auto resetting, current limit& thermal protection. ntegrated click & pop suppression
Power Source 12V DC @ 2.5A ( supplied ) or 18V DC @ 3.5A
Power Connector 2.1mm DC connector, centre
No signal current (12V) 28mA
Standby current (12V) 10mA
