Mains power supply

Voltage -EU versions

230 VAC ±10%, 50/60 Hz (reduced power at lower mains voltage)

Inrush current

10 A

Power consumption

 400 VA

Performance

Frequency response (Line)

60 Hz to 20 kHz (+1/‑3 dB @ ‑10 dB ref. rated output)

Frequency response (Mic.)

70 Hz to 20 kHz (+1/‑3 dB @ ‑10 dB ref. rated output)

Distortion

<1% @ rated output power, 1 kHz

Bass Control

Max. ± 8 dB

Treble Control

Max. ± 8 dB

Mic./Line input

4 x

Input 1 (push-to-talk contact with priority)

5‑pin Euro style, balanced, phantom

Input 2

3‑pin Euro style, balanced, phantom

Input 3 and 4

TRS Jack (1/4, 6.3mm) balanced

Sensitivity

1 mV (mic.); 300 mV (line)

Impedance

>1 kohm (mic.); >5 kohm (line)

Dynamic range

93 dB

S/N (flat at max volume)

>63 dB (mic.); >70 dB (line)

S/N (flat at min volume/muted)

>75 dB

CMRR (mic.)

>40 dB (50 Hz to 20 kHz)

Headroom

>25 dB

Speech filter

-3 dB @ 315 Hz, high-pass, 6 dB/oct

Phantom power supply

16 V via 1.2 kohm (mic.)

Music input

Connector

Cinch, stereo converted to mono

Sensitivity

200 mV

Impedance

22 kohm

S/N (flat at max volume)

>75 dB

S/N (flat at min volume/muted)

>80 dB

Headroom

>25 dB

Loudspeaker output

Connector

Screw terminal, floating

Max / rated PLE-1ME120‑xx

180 W / 120 W

Loudspeaker output

4 ohm

Connector

Screw terminal, floating

Physical

Dimensions (H x W x D)

100 x 430 x 270 mm (19" wide, 2U high)

Mounting

Stand-alone, 19" rack

Color

Charcoal

Weight

Approx. 8.9 kg
