Bosch LHM 0606/10

Bosch LHM 0606/10

The Bosch LHM 0606/10 is a general purpose, 6 watt, 100 volt line, cost-effective ceiling loudspeaker.

Flush mounted into the ceiling, the LHM0606/10 speaker is rated at 6 watts and suitable for 100 volt line distributed sound systems.

Suitable for both speech and music and ideal for public address and background music systems in shops, schools, offices, hotels and restaurants.

Quick and easy to install using two integral spring loaded ceiling locking clamps.

The multi-wire cable provides 3 transformer tappings at 6, 3 or 1.5 watts.

  • Suitable for speech and music reproduction
  • Flush-mounting in ceiling cavity
  • Easy to install
  • Simple power setting


A steel fire dome is available to fit the LHM 0606 - when fitted, this prevents the spread of fire via the loudspeaker into the ceiling void. See LBC 3080/01 in related products.

List Ex VAT: £16.00
Log in for Trade Prices
CONTACT US

SPECIFICATIONS

Maximum power

9 w

Rated power

6 / 3 / 1.5W

Sound pressure level at 6 W / 1 W (1 kHz, 1 m)

92 dB / 84 dB (SPL)

Effective frequency range (-10 dB)

80 Hz to 18 kHz

Opening angle at 1 kHz/4 kHz (-6 dB)

175° / 55°

Rated voltage

100 V

Rated impedance

1667 ohm

Connector

flying leads

Diameter

199 mm (7.8 inch)

Maximum depth

70.5 mm (2.8 inch)

Ceiling thickness

9 to 25 mm (0.35 to 0.98 inch)

Mounting cut-out

165 mm + 5mm (6.5 inch + 0.2 inch)

Speaker diameter

152.4 mm (6 in)

Weight

620 g (1.37 lb)

Colour

White (RAL 9010)

DOWNLOADS

EC Declaration of Conformity: Bosch LHM 0606/10 EMC & Low Voltage Directive
Bosch LHM0606/10 Ceiling Loudspeaker
EC Declaration of Conformity: LHM0606/10
