Denon DN-300BR
Denon DN-300BR
Click to expand

Denon DN-300BR

The Denon DN-300BR Bluetooth 4.0 receiver provides an interface between Bluetooth-enabled audio sources and a professional audio system for sound reinforcement and background music.

Rack mountable and only 1 RU high.

The DN300BR stores up to 8 devices in its internal memory.

A Bluetooth antenna is included and this can be connected to the front or rear of the receiver.

Ideal for playing music from a mobile phone, iPad, computer or other Bluetooth enabled device.

An optional remote pairing button can be fitted using the 2 pin Euroblock connector on the rear - ideal if the sound system is racked securely in a different room.



  • 1 RU rackmount receiver
  • Adds stereo Bluetooth 4.0 reception to any audio system
  • Remembers up to (8) Bluetooth devices
  • Balanced XLR and unbalanced RCA output
  • Remote pairing button connection on rear (Euroblock mating connector included)
  • BNC antenna input for Denon remote Bluetooth antenna (included)



1U bluetooth
List Ex VAT: £108.33
Log in for Trade Prices
CONTACT US

SPECIFICATIONS

Frequency Response

20 Hz – 18 KHz (+1 dBu)

Signal to Noise Ratio

> 83dB (1 kHz, Unity)

THD

< 0.33% (1 kHz, Unity)

Channel Separation

< -68dB (1 kHz, Unity)

Output Level

Balanced: =4dBu
Unbalanced: -10dBv

Bluetooth Version

Version 4.0

Receiver Range

Up to 100 feet / 30.5 meters

Receiver Sensitivity

-80 dBm @ 0.1% BER

Supported Codec

SBC, MP3, AAC, aptX

Supported Profiles

GAVDP 1.2, AVDTP 1.0, A2DP 1.2, Hands-Free Profile 1.5, Headset Profile 1.1

Output Class

Class 2

Dimensions (mm)

With Rach Ears: 19.0" x 10.7" x 1.7" (483 x 271 x 44mm)

Without Rack Ears: 17.1" x 10.7" x 1.7" (434 x 271 x 44mm)

Weight

3kg

DOWNLOADS

Denon DN-300BR Datasheet
