Power source

220 - 240 V AC, 50 / 60 Hz or 24 VDC

Power / current consumption

520 W (at rated output), 238 W (EN 62368-1)

Frequency response

50 Hz - 20 kHz

Rated output

240 W

Finish

ABS resin, Steel plate, black

Dimensions

420 x 100.9 x 351.3 mm (W x H x D)

Weight

13.2 kg

Current consumption

15 A

Inputs

Line-in 0 dBV, 10 kΩ, balanced, screw terminal,

100 V line in: 40 dBV, 330 kΩ, unbalanced, screw terminal,

 Power remote control: Make contact

Outputs

Loop out: 0 dBV, 10 kΩ, balanced, screw terminal,

Speaker out: Balanced (floating),

High impedance: 42 Ω (100 V), 21 Ω (70 V), Low impedance: 4 Ω (31 V)

Number of channels

1

Indicator

Power, signal, peak
