Tascam CD-200
Click to expand

Tascam CD-200

The TASCAM CD-200 single CD player is a simple, cost-effective CD player for installations or PA rental.

There are a number of features includng a headphone output with level control, intro check, anti-shock memory, and a variety of convenient playback modes which can help prevent the user from making a mistake.

Theres also pitch control with an on/off knob - ideal for dance or fitness classes.

The CD200 can also play back MP3 and WAV files from data CDs and display ID3 tags and CD-Text. The included wireless remote control gives access to most features and allows a track to be selected directly via a 10-key pad.

  • High-quality TEAC drive (supports CD-R and CD-RW)
  • Audio CD playback
  • MP3 and WAV file playback from CD
  • Folder selection for MP3 and WAV CDs
  • Continuous, Random and Program playback modes
  • Repeat playback (Single, All, Folder)
  • Intro Check feature
  • CD text and ID3 tag support to display artist and track information if available
  • Time display (CD-DA: Elapsed, Remain, Total Remain; MP3: Elapsed)
  • ±12.5 % pitch control
  • Anti-shock memory (10 seconds)
  • Headphones output with level control
  • Analogue output (RCA)
  • SPDIF digital outputs (coaxial and optical)
  • Wireless remote control included
  • 19-inch rack-mount chassis (2U)

2U CD Pitch
List Ex VAT: £296.66
Log in for Trade Prices
CONTACT US

SPECIFICATIONS

Audio Specification



CD Drive

Compatible discs:CD-R/CD-RW (12-cm/8-cm)
Formats: CD-DA, CD-ROM (ISO 9660 Level 1, 2, 3 JOLIET Romeo UDF 1.5), MP3, WAV

MP3 Playback Spec

Audio Mode: Stereo/Joint Stereo/Dual Channel/Mono/VBR
MPEG1 Audio Layer III (MP3)
Sampling frequency: 32 kHz/44.1 kHz/48 kHz
Bit rate: 32–320 Kbit/s

WAV playback specifications

Sampling frequency: 8 kHz/11.025 kHz/12 kHz/16 kHz/22.05 kHz/24 kHz/32 kHz/44.1 kHz/48 kHz

Audio performance



Frequency Response

20 Hz – 20 kHz (+/- 1.5dB)

Dynamic Range

90 dB min.

Signal-to-Noise Ratio

> 90 dB (20 kHz LPF)

Distortion (THD+N)

< 0.01% (1 kHz: 20 kHz LPF)

Channel separation

90 dB min. (1 kHz, 1 kHz BPF)

Audio outputs



Analogue output unbalanced

RCA pin jacks

Nominal output level

–10 dBV

Maximum output level

+6 dBV

Output impedance

200 Ω

Headphones output

Standard stereo jack

Nominal output power

20 mW + 20 mW min.
(When monitoring CD, THD+N: 0.1% max., 32 Ω load)

Coaxial digital output

RCA pin jack

Compatible signal format

IEC-60958-3 (SPDIF)

Output impedance

75 Ω

Optical digital output

Fibreoptic connector

Compatible signal format

IEC-60958-3 (SPDIF)

Power requirements

AC 230 V, 50 Hz (UK/Europe)

Dimensions  (WDH)

481 mm x 95 mm x 298 mm

Weight

4.2 kg
