Signet APXM

SigNET APXM Outreach plate with XLR microphone input socket.

The APXM is part of the SigNET range of Outreach plates which can be used to extend the functionality of your audio frequency induction loop system (AFILS).

Mountable on 25mm back boxes, each plate features a built-in mixer, pre-amp, input level control and balanced output. Fitting at the most convenient point on an installation overcomes the need for long and potentially hazardous microphone/audio leads.

Typically, up to 10 Outreach plates (any mix) can be daisy-chained to one balanced line level input with cable lengths of up to 100m easily achievable using standard two-pair audio cable with no recognisable degradation of audio signal quality.

Accepts balanced or unbalanced microphones
3 pin XLR input
On-board mic to line converter
High gain pre-amplifier
8v phantom supply
Single gang electrical face plate

Each outreach plate requires four wires, two balanced line (A +, A –), one ground (0V) and one power connection (12-32 V DC regulated).

List Ex VAT: £36.29

SPECIFICATIONS

Input – balanced / unbalanced line	1v (0dbv)
Output - balanced line	1v (0dbv) + 6db (overload)
Frequency response	40Hz - 20kHz
Input impedance	>10KΩ
Output impedance	<100Ω
Insertion loss/gain	< ± 0.05db
Insertion signal to noise ratio	>95db
Insertion THD + noise	<0.01%

DOWNLOADS

SigNET Outreach Plates

Signet Outreach Plates Instruction Manual

SigNET Guide to Assistive Listening

EC Declaration of Conformity: All Signet Loop Products
