TOA PC-1860BS

TOA PC-1860BS

The TOA PC-1860BS is a flush mount ceiling loudspeaker for voice alarm systems. Rated 6 watts on 100 volt line and is fully compliant with British Standard BS5839 Part 8 and EN 54-24.

This smart bezel free design speaker is easy to fit with wire springs which are designed in such a way as to minimise the chance of scratching the ceiling during installation.

Safety features include a ceramic terminal block, thermal fuse and safety wire connection as well as a steel fire dome to prevent the fire from spreading in the ceiling void.

All metal construction.

100V Evac
List Ex VAT: £30.00
Log in for Trade Prices
CONTACT US

SPECIFICATIONS

Rated Power (rms) 6 W (100 V Line), 3 W (70 V Line)
Impedance

100 V line: 1.7 k (6 W), 3.3 k (3 W), [6.7 k (1.5 W), 13 k (0.8 W)

70 V line: 1.7 k (3 W), 3.3 k (1.5 W), [6.7 k (0.8 W), 13 k (0.4 W)
SPL (1W/1m) 95 dB (1 W, 1 m) (500 Hz - 5 kHz, pink noise)
93 dB (1 W, 1 m) (100 Hz - 10 kHz, pink noise)
81 dB (1 W, 4 m) (100 Hz - 10 kHz, pink noise)
Max SPL (rated/1m) 100 dB (6 W, 1 m) (100 Hz - 10 kHz, pink noise)
88 dB (6 W, 4 m) (100 Hz - 10 kHz, pink noise)
Frequency Range 170 Hz - 20 kHz (peak -20 dB)
Connection 2-Steatite connector (3 pole)
Material & Finish Frame: Steel plate, white (RAL 9016 equivalent), paint
Grille: Steel net, white (RAL 9016 equivalent), paint
Fire dome: Steel plate, black, paint
Dimensions mm 180 Ø x 5(exposed section) + 100 (D) mm
Weight (kg) 1.1
Mounting Spring catch
